SmartDrive 2.0

Wemo SmartDrive 2.0 is a flexible and high-performance servo axis system developed to simplify the management of movements in automated applications. The system is ready to be integrated directly into your robot cell - suitable for everything from single motion to multi-axis pick-and-place solutions.
Discover Our RobotsContact Us

SmartDrive 2.0



Available in several different configurations and stroke lengths. Choose from one, two or three axes to build infeed, transfer, assembly or inspection.

MediaMedia
Smartdrive W-SS1
A servo-driven single-axis drive optimized for applications where the entire axis needs to be moved with high precision and repeatability.
MediaMedia
Smartdrive W-SD1
A servo-driven single-axis unit with belt drive, designed for precise movements and high load capacity in a modular format.
MediaMedia
Smartdrive W-DD2
The W-DD2 is a flexible two-axis unit for fast and precise pick & place applications, where both horizontal and vertical movement is required.
MediaMedia
Smartdrive W-DP2
The W-DP2 is a servo-driven pick & place unit with horizontal and vertical movement - optimized for high accuracy in confined spaces.
MediaMedia
Smartdrive W-TP3
The W-TP3 is a complete three-axis belt-driven robot package designed for complex handling tasks where movement is required in three directions.
MediaMedia
Smartdrive W-TG3
The W-TG3 is a high-performance 3-axis robot solution with pick & place concept, adapted for demanding applications in injection molding and material handling.

Three strengths that make a difference



The system is built to grow with your application. Choose from different axle combinations, accessories and profiles.
Modularity
SmartDrive 2.0 is designed with planetary gears and linear guides that provide good repeatability.
Precision
The system is controlled via WIPS and fits perfectly with Wemo robots, grippers, vision and other devices in the cell.
Integration

Created for movement in the right direction

Behind every SmartDrive unit is a clear function - efficient, stable and precise motion management for your production.

Media

Multiple configurations

SmartDrive is available in single, double and triple axis variants. Create the exact motion required for your process.
Media

Fast and quiet operation

All axles are belt-driven with planetary gears and are optimized for low noise, fast accelerations and low cycle times.
Media

Withstands heavy loads

With dual linear guides and high torsional rigidity, you can handle loads up to 20 kg with high accuracy.
Media

Expandable with accessories

Add rotating modules, vacuum units or valve islands - either on the trolley or the profile.

Examples of applications

SmartDrive 2.0 can be used in everything from vision systems to pick-and-place, assembly, buffer solutions and pallet handling. See how our customers use the system to streamline production flows in practice.

Our Automation Solutions
Media

Maximum movement, minimum effort

SmartDrive 2.0 is designed to give you full freedom of movement with minimum complexity. The system comes complete with pre-installed energy chains, motors, mounting plates and cabling. Everything is adapted for quick installation in robot cells, machine frames or stand-alone applications. The result is a shorter lead time from concept to operation - without compromising on performance.

Request a Quote
Media

Downloads



Accessories



Media
W-AMA1 – Adjustable mounting adapterThis adapter plate is designed for crosswise attachment on the broad side of the profile and is compatible with machine frames made from welded steel or aluminum profiles. It offers two hole patterns for easy integration with Item or Bosch profiles. Additionally, the plate includes two sets of adjustable screws, allowing precise leveling of the axis to the machine frame for optimal alignment and stability.
Media
W-AMA2 – Adjustable mounting adapterThis adapter plate is designed for lengthwise attachment along the narrower side of the profile. It features two hole patterns, making it compatible with both Item and Bosch profiles, ensuring flexible and secure integration.
Media
W-APP1 – Adapter plate on smart drive profileThis adapter plate is used for adding valves, vacuum venturi or connection boxes on smartdrive profiles for the types W-DD2, DP2, TP3 and TG3
Media
W-APW1 – Adapter plate on wagonThis adapter plate is used for adding valves, vacuum venturi or connection boxes on movable wagon platen for the types W-DD2, DP2, TP3 and TG3
Media
Externally mounted wider energy cable chainsFor applications requiring additional cables or tubes, an external energy chain can be attached to the horizontal axes. The internal dimensions of the chain measure 52 x 22.5 mm (W x H), providing space for extra components while maintaining organized and efficient cable management.
Media
Slot nuts – Fastening kitsSlot nuts and profiles are designed for attaching accessories to Smartdrive modules. The slot nuts come with threaded dimensions in M5, M6, and M8, while the slot nut profile allows for customized thread patterns based on specific applications. Each set includes 10 slot nuts, and the profile is provided in a 1000 mm length, offering flexibility for various mounting needs.
Media
Rotary module C for horizontal rotation around vertical axesThis pneumatic-driven module enables an additional horizontal rotation around the vertical axis, offering enhanced flexibility in automation processes. It includes an adapter plate for direct mounting beneath the vertical axis, ensuring a seamless and stable integration.
Media
Wrist rotary module B for rotation from vertical plane to horizontal planeThis pneumatic-driven module enables an additional wrist rotation around the vertical axis, enhancing flexibility in robotic operations. It comes with an adapter plate for direct assembly beneath the vertical axis, ensuring secure and precise integration.
